190hp flat bed truck custom– 6×6 off-road special truck manufacturer
Product Description
Dongfeng EQ2102, as one of the core products of China EAC, excellent cost performance, comfort, safety, flexibility and reliability are its characteristics. It can take personalized customization service according to customers’ needs, and has long been concerned by foreign users. This 6*6 complete vehicle adopts EQ2101 military chassis process, which not only inherits the off-road performance of military vehicles, but also matches the upgraded comfort of the cab, which is more in line with the current market demand.
Product Parameter
| Basic Configuration | |
| Drive Mode | 6×6 |
| Engine | Cummins B190 33 |
| Gearbox | Mechanical Manual six speed |
| Transfer case | High-low speed |
| Cab | Dongfeng flathead one and a half row (with sleeper) |
| Axle | Max. Load 3.6Tons/3.6Tons/3.6Tons (Front/Middle/Rear) |
| Tyre | 12.5R20 (6 + 1) |
| Spring steel plate | 10/12 pieces |
| Other | 24V circuit system |
| Performance Parameter | |||
| Overall Dimension(mm) | 7965 × 2480 × 3020(Length×Width×Height) | ||
| Cargobox Dimension(mm) | 4800 × 2300 × 900(Length×Width×Height) | ||
| Total Mass(kg) | 10745 | Curb Weight(kg) | 6670 |
| Max. Power(kW/rpm) | 155 | Max. Torque(N.m) | 640 |
| Wheelbase(mm) | 1920 | Displacement(L) | 5.9 |
| Approach Angle (°) | 24 | Departure Angle (°) | 28 |
| Ground Clearance(mm) | 310 | Fording depth (mm) | 1150 |
| Front Suspension(mm) | 1515 | Rear Suspension(mm) | 1630 |
| Frame upper plane off the ground(mm) | 1120 | Crossing height(mm) | 550 |
| Max. Speed(km/h) | 87 | Tank Capacity(L) | 300 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
