4×2 Dongfeng EQ5120 Field Training Camp Military Truck
Product Description
This vehicle is used for field training camp.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins ISDE210-30 |
| Gearbox | Mechanical six speed |
| Transfer case | High-low speed |
| Cab | Three seats |
| Axle | Max. Load 4.5Tons/9Tons (Front/Rear) |
| Tyre | 9.00-20 |
| Electrical appliance | 24V circuit system |
| Function configuration | 1.The carriage uses a folded bilateral board, which is increased to the internal support rod, and the detachable tent.2.Can be used as a regular high-fence military supplier
3. It is necessary to put a flat bilateral board and support the fixed tent when it is supported, and a high-level tent of 38 square meters can be used for approximately 36 people. |
| Performance Parameter | |||
| Overall Dimension(mm) | 8500 × 2470 × 2690(Length×Width×Height) | ||
| Cargo size(mm) | 6100×2210×930 | ||
| Total Mass(kg) | 12355 | Curb Weight(kg) | 6160 |
| Max. Power(kW/rpm) | 125 | Max. Torque(N.m) | 560 |
| Wheelbase(mm) | 4700 | Displacement(L) | 6.7 |
| Approach Angle (°) | 32 | Departure Angle (°) | 35 |
| Ground Clearance(mm) | 285 | Fording depth (mm) | 1100 |
| Max. Speed(km/h) | 107 | Turning radius （m） | ≯16 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
