4×4 pointed EQ2070 upgraded chassis – new 4WD 140 double axle off-road special truck – all-wheel-drive 190 hp cargo transportation manufacturer
Product Description
On the basis of the chassis of Dongfeng classic EQ2070 cross-country troop carrier, adding the tip 140 cab not only meets the market demand for 4WD chassis, but also enriches the new model products. This chassis can be modified according to the needs of dump trucks, flatbed trucks, green spraying trucks, compressed garbage trucks, fuel trucks, truck-mounted lifting trucks and so on.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins B190 33 |
| Gearbox | Manual five speed |
| Transfer case | High-low speed |
| Cab | Dongfeng pointed single-row |
| Axle | Max. Load 3.5Tons/3.5Tons (Front/Rear) |
| Tyre | 12R20 (4 + 1) |
| Circuit | 24V circuit system |
| Suspension | 9/10 |
| Frame | 860*160mm, thickness 8mm |
| Other | Heating and air conditioning, extractor |
| Performance Parameter | |||
| Chassis Dimension(mm) | 6131 × 2190 × 2660(Length×Width×Height) | ||
| Modification size(mm) | ≥3550 | ||
| Total Mass(kg) | 7910 | Curb Weight(kg) | 4270 |
| Max. Power(kW/rpm) | 140 | Overrun height(mm) | 515 |
| Wheelbase(mm) | 3430 | Displacement(L) | 5.9 |
| Approach Angle (°) | 27 | Departure Angle (°) | 28 |
| Ground Clearance(mm) | 315 | Fording depth (mm) | 1280 |
| The upper plane of the rear end of the frame is off the ground(mm) | 1180 | degree of climb (on a slope)(％) | 60 |
| Max. Speed(km/h) | 85 | Tank Capacity(L) | 210 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
