Product Description
This flat-head “Bobcat” off-road truck is a modified and upgraded version of “Hero” 25Y, which is a flat-head 6WD off-road truck launched by our company according to the demand and more in line with the market. This new vehicle inherits the superior performance of the original, but also has better functions and maneuverability.
Product Parameter
| Basic Configuration | |
| Drive Mode | 6×6 |
| Engine | Cummins B190 33 |
| Gearbox | Mechanical Manual five speed |
| Transfer case | High-low speed |
| Cab | Flathead one-and-a-half row glass cab |
| Axle | Max. Load2.7Tons/2.7Tons/2.7Tons (Front/Middle/Rear) |
| Tyre | 8.25R20 (10 + 1) |
| Other | 24V circuit system |
| Performance Parameter | |||
| Cab Dimension(mm) | 2035 × 2250× 2200(Length×Width×Height) | ||
| Overall dimension(mm) | 6260 × 2530× 2680(Length×Width×Height) | ||
| Modification size(mm) | 3700 | ||
| Total Mass(kg) | 8100 | Power(kw) | 125 |
| Max. Power(kW/rpm) | 1300 | Max. Torque(N.m) | 560 |
| Front Suspension(mm) | 1340 | Rear Suspension(mm) | 630 |
| Wheelbase(mm) | 3190+1100 | Fording depth (mm) | 535 |
| Ground Clearance(mm) | 280 | Tank Capacity(mm) | 860 × 400 × 480 |
| Max. Speed(km/h) | 87 | ||
This parameter is for reference only. The margin of error is plus or minus three percentage points.
