Dongfeng 4×2 Dump Truck Chassis
Product Description
4 × 2 Dongfeng chassis can be modified into ordinary trucks, dump trucks, flammable and explosive dangerous goods transport vehicles, refrigerated vehicles, warehouse cars, animal husbandry, logs, fresh milk transport vehicles, Oil, sprinkler, compressed garbage truck, RV.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins B190 33 |
| Gearbox | Nine speed |
| Transfer case | High-low speed |
| Cab | Three seats, Dongfeng Tianjin flat head |
| Axle | Max. Load 5Tons/16Tons (Front/Rear) |
| Tyre | 11.00R20 (6+1) |
| Electrical appliance | 24V circuit system |
| Performance Parameter | |||
| Overall Dimension(mm) | 7300 × 2580 × 3050(Length×Width×Height) | ||
| Modification size(mm) | 4700 | ||
| Total Mass(kg) | 21500 | Curb Weight(kg) | 7800 |
| Max. Power(kW/rpm) | 177 | Max. Torque(N.m) | 900 |
| Wheelbase(mm) | 4500 | Displacement(L) | 7.25 |
| Approach Angle (°) | 18 | Departure Angle (°) | 13 |
| Ground Clearance(mm) | 335 | Fording depth (mm) | 530 |
| Max. Speed(km/h) | 85 | Tank Capacity(L) | 280 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
