Dongfeng 6×4 Off-road Dump Truck

Short Description:


Product Detail

Product Tags

Product Description

Dongfeng 6×4 Drive Off-road Dump Truck

Product Parameter

Basic Configuration
Drive Mode 6×4
Engine YC6J210-33
Gearbox Mechanical Manual eight speed
Transfer case High-low speed
Cab Three seats
Axle Max. Load 5Tons/10Tons/10Tons (Front/Middle/Rear)
Tyre 10.00R20 (10 + 1)
Electrical Appliance
24V circuit system
Performance Parameter
Overall Dimension(mm) 7830 × 2500 × 3280(Length×Width×Height)
Cargo size(mm) 5200×2300×1100
Total Mass(kg) 20350 Curb Weight(kg) 10165
Max. Power(kW/rpm) 156 Max. Torque(N.m) 710
Wheelbase(mm) 3500+1300 Displacement(L) 6.5
Approach Angle (°) 30 Departure Angle (°) 48
Ground Clearance(mm) 285 Fording depth (mm) 600

This parameter is for reference only. The margin of error is plus or minus three percentage points.
