Dongfeng 8*4 Type Three Chassis–420 hp Cargo Truck Chassis Conversion Manufacturer–Export Special Purpose Vehicle Chassis
Product Description
The 8*4 off-road vehicle class III chassis is a chassis model designed one-to-one by our company according to the customer’s requirements. After multi-faceted design, testing and perfecting, the chassis’ passability reaches the customer’s indexes. The chassis cab and top load are perfected by customers themselves, and will be exported to Africa for use.
Product Parameter
| Basic Configuration | |
| Engine | Yuchai YC6MK420-33 |
| Gearbox | Mechanical Manual twelve speed |
| Axle | Max. Load 5Tons/5Tons/10Tons/10Tons (Front/Middle/Rear) |
| Tyre | 11.00R20(12+1) |
| Frame | 860×280，8+6 |
| Suspension | Steel spring plate, 9/9/10 |
| Performance Parameter | |||
| Type III chassis dimensions | 11740× 2510× 1830(Length×Width×Height) | ||
| The upper plane of the rear end of the frame is off the ground(mm) | 1090 | ||
| Axlebase(mm) | 1850+4650+1350 | Wheelbase(mm) | 1990/1870 |
| Max. Power(kW/rpm) | 309 | Displacement(L) | 6.7 |
| Max. torque(N.m) | 1100 | Departure Angle (°) | 11 |
| Approach Angle (°) | 29 | Overrun height (mm) | 410 |
| Ground Clearance(mm) | 310 | Fuel tank volume(L) | 380 |
| Max. speed(km/h) | 95 | ||
This parameter is for reference only. The margin of error is plus or minus three percentage points.
