Dongfeng EQ2070 Flat Head Four wheel drive Off-road Truck
Product Description
ongfeng EQ2070G double row off-road truck adopts Dongfeng 153 flat head cab. Can be assembled with 170 or 190 horsepower engine, can carry goods in the container, but also collapsed seat transport personnel, with a tent cloch rod to avoid soaking and wind erosion in the container.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins B170 33 |
| Gearbox | Mechanical Manual five speed |
| Transfer case | Part-time five wheel drive, high-low speed |
| Cab | Dongfeng flat head one and a half row, three seats |
| Axle | Max. Load 3.6Tons/4.3Tons (Front/Rear) |
| Tyre | 12.5R20 (4+1) |
| Traction connection device | Traction hook (front / rear), can choose a front winch, traction 44100N |
| Performance Parameter | |||
| Overall Dimension(mm) | 6500×2470×2700(Length×Width×Height) | ||
| Cargo Dimension(mm) | 3545×2294×900(Length×Width×Height) | ||
| Total Mass(kg) | 7190 | Curb Weight(kg) | 2500 |
| Max. Power(kW/rpm) | 125/2500 | Tank Capacity(L) | 160 |
| Wheelbase(mm) | 3190+1100 | Displacement(L) | 5.9 |
| Approach Angle (°) | 45 | Departure Angle (°) | 44 |
| Ground Clearance(mm) | ≤305 | Fording depth (mm) | 1035 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
