Dongfeng EQ2070 Four Drive Off-road Truck

Short Description:


Product Detail

Product Tags

Product Description

Dongfeng EQ2070G off-road carrier as a classic domestic military vehicle, performance stability is the biggest feature of this vehicle, making the car favored by people around the world. The chassis uses Dongfeng 153 cab, all of which use military standards, as a military chassis, long-term off-road performance is the most basic, in various advantages, the chassis is often used to modify the green sprinkler , Dump trucks, garbage trucks, vanes, etc.

Product Parameter

Basic Configuration
Drive Mode 4×4
Engine Cummins B190 33
Gearbox Mechanical Manual five speed
Transfer case High-low speed
Cab Three seats
Axle Max. Load 3.5Tons/3.5Tons (Front/Rear)
Tyre 12.5R20 (4 + 1)
Other Hydraulic steering power, exhaust braking
Performance Parameter
Overall Dimension(mm) 7000 × 2460 × 2820(Length×Width×Height)
Modification size(mm) 4700
Total Mass(kg) 7910 Curb Weight(kg) 4550
Max. Power(kW/rpm) 140 Max. Torque(N.m) 640
Wheelbase(mm) 4200 Displacement(L) 5.9
Approach Angle (°) 32 Departure Angle (°) 35
Ground Clearance(mm) 310 Fording depth (mm) 550
Max. Speed(km/h) 85 Tank Capacity(L) 120

This parameter is for reference only. The margin of error is plus or minus three percentage points.
