Dongfeng EQ2070 Four wheel drive Off-road Vehicle Modified RV
Product Description
Dongfeng EQ2070G off-road carrier as a classic domestic military vehicle, performance stability is the biggest feature of this vehicle, making the car favored by people around the world. The chassis uses Dongfeng 153 cab, all of which use military standards, as a military chassis, long-term off-road performance is the most basic, in various advantages, the chassis is often used to modify the green sprinkler , Dump trucks, garbage trucks, vanes, etc. This RV is modified by Dongfeng EQ2070.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins B190 33 |
| Suspension | Front and rear steel plate spring suspension; front suspension 2 two-way shock absorbers; rear suspension frame 4 two-way shock absorbers; |
| Cab | Dongfeng EQ2070 row semi-cab, with roll-roll bracket, top with luggage frame, two high-power searchlights, with anti-collision cylinders |
| Axle | Max. Load 3.5Tons/3.5Tons (Front/Rear) |
| Tyre | 14.00R20 military off-road tyre; 2 after the tires are hung in the tail of the vehicle |
| Electrical appliance | 24V circuit system |
| Performance Parameter | |||
| Overall Dimension(mm) | 6900 × 2500 × 3780(Length×Width×Height) | ||
| Total Mass(kg) | 11000 | Curb Weight(kg) | 8820 |
| Max. Power(kW/rpm) | 140 | Load quality(kg) | 2180 |
| Wheelbase(mm) | 3600 | Displacement(L) | 5.9 |
| Approach Angle (°) | 35 | Departure Angle (°) | 32 |
| Ground Clearance(mm) | 400 | Max. Gradeability (°) | 60 |
| Max. Speed(km/h) | 88 | Tank Capacity(L) | 120 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
