Dongfeng EQ2082 Six Drive Double Glass Cab Military Vehicle
Product Description
Dongfeng EQ2082 off-road carrier as a classic domestic military vehicle, performance stability is the biggest feature of this vehicle, making the car favored by people around the world. The chassis uses Dongfeng long head single row cab, all of which use military standards, as a military chassis, long-term off-road performance is the most basic, in various advantages, the chassis is often used to modify the green sprinkler , Dump trucks, garbage trucks, vanes, etc.
Product Parameter
| Basic Configuration | |
| Drive Mode | 6×6 |
| Engine | Cummins EQ6BT5.9 |
| Gearbox | Mechanical Manual five speed |
| Transfer case | High-low speed |
| Cab | Three seats,long head Single-row flat glass cab, all metal welding closed structure, The rear window is provided with a protective net, the cab front cover light has a protective net, which is equipped with air defense lamps. |
| Axle | Max. Load 2.6Tons/2.6Ton/2.6Tons(Front/Middle/Rear) |
| Tyre | 11R18 (6 + 1) |
| Electrical appliance | 24V circuit system |
| Performance Parameter | |||
| Overall Dimension(mm) | 6340 × 2400 × 2385(Length×Width×Height) | ||
| Cargo size(mm) | 3545 × 2180 × 900 | ||
| Total Mass(kg) | 7800 | Curb Weight(kg) | 5090 |
| Max. Power(kW/rpm) | 125 | Load Weight(kg) | 2500 |
| Wheelbase(mm) | 3190 + 1100 | Displacement(L) | 5.9 |
| Approach Angle (°) | 45 | Departure Angle (°) | 44 |
| Ground Clearance(mm) | 285 | Fording depth (mm) | 1100 |
| Max. Speed(km/h) | 87 | Tank Capacity(L) | 160+60 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
