Dongfeng EQ2100 Six Drive Long Head Off-road Truck Chassis
Product Description
Dongfeng EQ2100 Dump Truck is equipped with Dongfeng Cummins ISB190 40 engine,
Product Parameter
| Basic Configuration | |
| Drive Mode | 6×6 |
| Engine | Cummins ISB190 40 |
| Gearbox | Mechanical Manual six speed |
| Transfer case | Part-time six wheel drive, high-low speed |
| Cab | Dongfeng flat head single row, three seats |
| Axle | Max. Load 3.6Tons/3.6 Tons/3.6Tons (Front/ middle/Rear) |
| Tyre | 12.5R20 (6+1) |
| Electrical applicance | 24 circuit system |
| Performance Parameter | |||
| Overall Dimension(mm) | 7880×1910×2480(Length×Width×Height) | ||
| Modification Dimension(mm) | 4950 | ||
| Total Mass(kg) | 10800 | Curb Weight(kg) | 5380 |
| Max. Power(kW/rpm) | 140/2500 | Tank Capacity(L) | 160+60 |
| Wheelbase(mm) | 3475+1250 | Displacement(L) | 5.9 |
| Approach Angle (°) | 30 | Departure Angle (°) | 30 |
| Max. Speed(km/h) | 87 | Max. gradeabilty (%) | 60 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
