Dongfeng EQ210G Six Drive Off-road Fuel Tank&Refuelling Truck
Product Description
Dongfeng EQ2102G off-road carrier as a classic domestic military vehicle, performance stability is the biggest feature of this vehicle, making the car favored by people around the world. This Fuel Tank&Refuelling Truck is modified from Dongfeng EQ2102G.
Product Parameter
Basic Configuration | |
Drive Mode | 6×6 |
Engine | CumminsISB190 40 |
Gearbox | Mechanical Manual six speed |
Transfer case | High-low speed |
Cab | Three seats, new Dongfeng 153 cab |
Axle | Max. Load 3.5Tons/3.5Tons (Front/Rear) |
Tyre | 12.5R20 (4 + 1) |
Other | Hydraulic steering power, exhaust braking |
Performance Parameter | |||
Overall Dimension(mm) | 7230×2460×2705(Length×Width×Height) | ||
Tank Volume(m³) | 6 | ||
Total Mass(kg) | 10800 | Curb Weight(kg) | 7700 |
Max. Power(kW/rpm) | 140 | Max. Torque(N.m) | 640 |
Wheelbase(mm) | 3475 + 1250 | Displacement(L) | 5.9 |
Approach Angle (°) | 30 | Departure Angle (°) | 22 |
Ground Clearance(mm) | 315 | Max. Gradeability(%) | 60 |
Max. Speed(km/h) | 87 | Tank Capacity(L) | 160+60 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
![](https://www.fydftruck.com/uploads/1772e96f.jpg)
![](https://www.fydftruck.com/uploads/26a70e4f59063d2e171d25b0862413d.jpg)
![](https://www.fydftruck.com/uploads/87664ffc.jpg)
![](https://www.fydftruck.com/uploads/239351748510301bcc7c3bdd2b192cf.jpg)
![](https://www.fydftruck.com/uploads/936fe671774725b5c3f66b4616afb23.jpg)
![](https://www.fydftruck.com/uploads/efc3beee.jpg)
![](https://www.fydftruck.com/uploads/49d52581.jpg)
![](https://www.fydftruck.com/uploads/93243e7e1d10f205d5a7493a717b59f.jpg)
