Dongfeng EQ5120XLHL6D Training Truck Classic Model Off-road Vehicle
Product Description
Dongfeng EQ5120XLHL6D Training Truck
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×2 |
| Engine | YCY24120-60 |
| Gearbox | Manual five speed |
| Cab | Dongfeng Pointed-head single-row, 3 seats |
| Leaf Spring | 7/10 |
| Tyre | 9.00R20(6+1) |
| Frame | 860×140×70 |
| Performance Parameter | |||
| Overall Dimension(mm) | 9000×2480×2550(Length×Width×Height) | ||
| Compartment Dimension(mm) | 6050×2300×550（Length×Width×Height） | ||
| Total Mass(kg) | 12400 | Curb Weight(kg) | 4315 |
| Max. Power(kW/rpm) | 88 | Max. Torque(N.m) | 320 |
| Wheelbase(mm) | 5200 | Displacement(L) | 2.36 |
| Wheel Track(mm) | 1820/1800 | Cylinder | 4 |
| Front Overhang(mm) | 1050 | Rear Overhang(mm) | 2750 |
| Approach Angle (°) | 19 | Departure Angle (°) | 12 |
| Ground Clearance(mm) | 255 | Fording depth (mm) | 450 |
| Max. Speed(km/h) | 88 | Tank Capacity(L) | 160 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
