Dongfeng flat-head all-drive off-road truck–Bobcat two-and-a-half-ton diesel off-road troop carrier– Dongfeng 6*6 road transport truck
Product Description
The “Bobcat” all-drive off-road truck is improved on the basis of Dongfeng classic EQ2082E6D two-and-a-half-ton long-head diesel off-road truck. The cab adopts a flat-head one-and-a-half row cab, which is comfortable and luxurious with spacious view. The same length, more powerful function, at the same time added 300L brake cooling water tank and large-capacity tool box. The bottom plate of the cargo box is made of pure iron with anti-skid pattern. The two side panels are installed with folding seats, and the rear part has 2 folding ladders.
Product Parameter
| Basic Configuration | |
| Engine | Cummins B210 33 |
| Gearbox | Mechanical Manual six speed |
| Transfer case | High-low speed |
| Cab | Three seats |
| Axle | Max. Load 2.5Tons/2.5Tons/2.5Tons (Front/Middle/Rear) |
| Tyre | 11R18 (6 + 1) |
| Suspension | Steel plate springs 9/13 |
| Other | Water bucket, oil drum, fire extinguisher, accompanying tools, cloths and poles |
| Performance Parameter | |||
| Overall Dimension(mm) | 6720 x 2480 x 3350(Length×Width×Height) | ||
| Cargobox Dimension(mm) | 3600 x 2300 x 2250(Length×Width×Height) | ||
| Total Mass(kg) | 7800 | Curb Weight(kg) | 5250 |
| Max. Power(kW/rpm) | 125 | Maximum climbing grade(％) | 60 |
| Wheelbase(mm) | 3130+1065 | Displacement(L) | 5.9 |
| Approach Angle (°) | 27 | Departure Angle (°) | 43 |
| Ground Clearance(mm) | 310 | Fording depth (mm) | 1100 |
| Max. Speed(km/h) | ≥87 | Tank Capacity(L) | 160 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
