Dongfeng Light-duty Commercial Truck
Product Description
This vehicle is Dongfeng light-duty truck series.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins B140, straight four cylinder, medium cooling, water cooling, four stroke |
| Gearbox | Mechanical Manual five speed |
| Transfer case | High-low speed |
| Cab | Three seats |
| Axle | Max. Load 2.7Tons/7Tons (Front/Rear) |
| Tyre | 8.25-20 (6 + 1) |
| Electrical Appliance | 24V circuit system |
| Other | Hydraulic steering power, exhaust braking |
| Performance Parameter | |||
| Overall Dimension(mm) | 6930 × 2225 × 2750(Length×Width×Height) | ||
| Modification size(mm) | 3950 | ||
| Total Mass(kg) | 9000 | Curb Weight(kg) | 2500 |
| Max. Power(kW/rpm) | 104 | Max. Torque(N.m) | 290 |
| Wheelbase(mm) | 3950 | Displacement(L) | 3.9 |
| Approach Angle (°) | 30 | Departure Angle (°) | 26 |
| Ground Clearance(mm) | 285 | Min. Turning radius (mm) | 550 |
| Max. Speed(km/h) | 88 | Tank Capacity(L) | 160 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
