Dongfeng Six drive flat head new EQ2082 off-road chassis
Product Description
Dongfeng EQ202082 off-road carrier as a classic domestic military vehicle, performance stability is the biggest feature of this vehicle, making the car favored by people around the world. This chassis is the update of classic EQ2082 vehicle chassis. This chassis uses Dongfeng D912 cab, all of which use military standards, as a military chassis, long-term off-road performance is the most basic, in various advantages, the chassis is often used to modify the green sprinkler , Dump trucks, garbage trucks, vanes, etc.
Product Parameter
| Basic Configuration | |
| Drive Mode | 6×6 |
| Engine | Cummins B170 33 |
| Gearbox | Mechanical Manual five speed |
| Transfer case | High-low speed |
| Cab | Three seats, flat head Half-plane glass cab, all metal welding closed structure, the rear window is provided with a protective net, the cab front cover light is protected, including air defense lamp |
| Axle | Max. Load 3.5Tons/3.5Tons (Front/Rear) |
| Tyre | 11R18 |
| Electrical appliance | 24V circuit system |
| Performance Parameter | |||
| Overall Dimension(mm) | 6400 × 2200 × 2750(Length×Width×Height) | ||
| Modification size(mm) | 4700 | ||
| Total Mass(kg) | 7800 | Curb Weight(kg) | 5090 |
| Max. Power(kW/rpm) | 140 | Load Weight(kg) | 2500 |
| Wheelbase(mm) | 3240+1050 | Displacement(L) | 5.9 |
| Approach Angle (°) | 60 | Departure Angle (°) | 46 |
| Ground Clearance(mm) | 286 | Fording depth (mm) | 1055 |
| Max. Speed(km/h) | 87 | Tank Capacity(L) | 160+60 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
