Dongfeng Six drive long head EQ2100 off-road dump truck

Short Description:


Product Detail

Product Tags

Product Description

Dongfeng EQ2100G off-road carrier as a classic domestic military vehicle, performance stability is the biggest feature of this vehicle, making the car favored by people around the world.

Product Parameter

Basic Configuration
Drive Mode 6×6
Engine Cummins B190 33
Gearbox Mechanical Manual six speed
Transfer case High-low speed
Cab Three seats,long head metal welding closed structure
Axle Max. Load 3.5Tons/3.5Tons/3.5Tons (Front/Middle/Rear)
Tyre 12.00R20 (6 + 1)
Electrical Applicance 24V circuit system
Performance Parameter
Overall Dimension(mm) 7100 × 2420 × 2715(Length×Width×Height)
Cargo size(mm) 4200 × 2300 × 900
Total Mass(kg) 9800 Curb Weight(kg) 7150
Max. Power(kW/rpm) 140 Max. Torque(N.m) 640
Wheelbase(mm) 3650+1250 Displacement(L) 5.9
Approach Angle (°) 26 Departure Angle (°) 30
Ground Clearance(mm) 320 Fording depth (mm) 640
Max. Speed(km/h) 85 Tank Capacity(L) 140

This parameter is for reference only. The margin of error is plus or minus three percentage points.
