Dongfeng Six drive long head EQ2100 off-road dump truck
Product Description
Dongfeng EQ2100G off-road carrier as a classic domestic military vehicle, performance stability is the biggest feature of this vehicle, making the car favored by people around the world.
Product Parameter
| Basic Configuration | |
| Drive Mode | 6×6 |
| Engine | Cummins B190 33 |
| Gearbox | Mechanical Manual six speed |
| Transfer case | High-low speed |
| Cab | Three seats,long head metal welding closed structure |
| Axle | Max. Load 3.5Tons/3.5Tons/3.5Tons (Front/Middle/Rear) |
| Tyre | 12.00R20 (6 + 1) |
| Electrical Applicance | 24V circuit system |
| Performance Parameter | |||
| Overall Dimension(mm) | 7100 × 2420 × 2715(Length×Width×Height) | ||
| Cargo size(mm) | 4200 × 2300 × 900 | ||
| Total Mass(kg) | 9800 | Curb Weight(kg) | 7150 |
| Max. Power(kW/rpm) | 140 | Max. Torque(N.m) | 640 |
| Wheelbase(mm) | 3650+1250 | Displacement(L) | 5.9 |
| Approach Angle (°) | 26 | Departure Angle (°) | 30 |
| Ground Clearance(mm) | 320 | Fording depth (mm) | 640 |
| Max. Speed(km/h) | 85 | Tank Capacity(L) | 140 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
