Dongfeng Six Drive Long-head Single Row Dump Truck
Product Description
Dongfeng Six Drive Long-head Single Row Dump Truck.
Product Parameter
Basic Configuration | |
Drive Mode | 6×6 |
Engine | Cummins B170 33 |
Gearbox | Mechanical Manual five speed |
Transfer case | High-low speed |
Cab | Three seats |
Axle | Max. Load 3.5Tons/3.5Tons (Front/Rear) |
Tyre | 12.5R20 (6 + 1) |
Other | Hydraulic steering power, exhaust braking |
Performance Parameter | |||
Overall Dimension(mm) | 7100 × 2420 × 2715(Length×Width×Height) | ||
Cargo size(mm) | 4200×2300×900 | ||
Total Mass(kg) | 12500 | Curb Weight(kg) | 7100 |
Max. Power(kW/rpm) | 125 | Displacement(L) | 5880 |
Wheelbase(mm) | 3600+1250 | ||
Approach Angle (°) | 26 | Departure Angle (°) | 30 |
Ground Clearance(mm) | 320 | Fording depth (mm) | 640 |
Max. Speed(km/h) | 85 | Tank Capacity(L) | 140 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
