Dongfeng Four Drive Off-road Truck

Short Description:


Product Detail

Product Tags

Product Description

Dongfeng Four Drive Off-road Truck . The cab of this vehicle uses Dongfeng Tianjin cab, all of which use military standards. The chassis of this truck is often used to modify the green sprinkler , Dump trucks, garbage trucks, vanes, etc.

Product Parameter

Basic Configuration
Drive Mode 4×4
Engine Cummins B210 33
Gearbox 8JS85E-C
Transfer case High-low speed
Cab Three seats
Axle Max. Load 4.5Tons/6Tons (Front/Rear)
Tyre 12.5R20 (4 + 1)
Electrical appliance 24V Circuit system
Performance Parameter
Overall Dimension(mm) 7510 × 2300 × 3025(Length×Width×Height)
Cargo size(mm) 4950×2300×900
Total Mass(kg) 10435 Curb Weight(kg) 6710
Max. Power(kW/rpm) 155 Max. Torque(N.m) 700
Wheelbase(mm) 4200 Displacement(L) 5.9
Ground Clearance(mm) 320 Fording depth (mm) 1160
Max. Speed(km/h) 87 Tank Capacity(L) 320

This parameter is for reference only. The margin of error is plus or minus three percentage points.
