Four wheel drive Desert Off-road Surfing Vehicle
Product Description
The vehicle is a four-wheel drive desert sightseeing vehicle.We can provide customers with personalized services according to their needs.This car is big and full of power.In addition, it is also equipped with a special desert tyre.The outdoor passenger area with a height of 3580 mm can accommodate up to 18 passengers.The outdoor passenger area not only brings the excitement of desert surfing to passers-by, but also allows passengers to enjoy the magnificent panoramic view of the desert landscape.The vehicle is equipped with a Cummins 375 horsepower engine and a special desert tyre, which can help the vehicle drive fast in the desert.
Product Parameter
| Basic Configuration | |
| Drive Mode | 4×4 |
| Engine | Cummins 375 horsepower |
| Gearbox | Mechanical Manual nine speed |
| Transfer case | High-low speed with differential lock |
| Axle | Max. Load 9Tons/13Tons (Front/Rear) |
| Tyre | Desert Special Off-road Tyre |
| Other | Hydraulic steering power, exhaust braking |
| Special configuration |
|
| Performance Parameter | |||
| Overall Dimension(mm) | 10200×3400×3580(Length×Width×Height) | ||
| Modification size(mm) | 7600 | ||
| Total Mass(kg) | 22000 | Curb Weight(kg) | 8000 |
| Max. Power(kW/rpm) | 276 | Max. Torque(N.m) | 1480 |
| Wheelbase(mm) | 7600 | Displacement(L) | 8.9 |
| Approach Angle (°) | 50 | Departure Angle (°) | 34 |
| Ground Clearance(mm) | 605 | Braking distance (30km/h full load) (m) | 9 |
| Min. Turning Raduis(m) | 9 | Fording Depth(mm) | 1900 |
| Max. Speed(km/h) | 95 | Tank Capacity(L) | 300 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
