Four wheel drive flat head Compressed garbage truck
Product Description
The volume of this vehicle is 12. Used high-strength steel plate production (manganese plate), 4mm of the box, 4mm, the side plate 4mm, Ziyoubuilding equipment (import accessories), Hunan Honghui multi-channel valve; Hefei long source oil pump, two-way compression, rear installation The sealed bucket device, hydraulic lock uses domestic well-known brands, install Siemens electronic control system, driving indoor electrical control system, two side electron control systems, two-side sewage sewage, one of the filler, one, depressed installation only.
Product Parameter
| Basic Configuration | |
| Drive Mode | 6×6 |
| Engine | Cummins B170 33 |
| Gearbox | Mechanical Manual five speed |
| Transfer case | High-low speed |
| Cab | Three seats |
| Axle | Max. Load 2.5Tons/2.5Tons/2.5Tons(Front/Middle/Rear) |
| Tyre | 11R18 (6 + 1) |
| Electrical appliance | 24V circuit system |
| Other | Hydraulic clutch power, hydraulic steering power, exhaust braking |
| Performance Parameter | |||
| Overall Dimension(mm) | 6340 × 2400 × 2385(Length×Width×Height) | ||
| Cargo size(mm) | 3545 × 2180 × 900 | ||
| Total Mass(kg) | 7800 | Curb Weight(kg) | 5090 |
| Max. Power(kW/rpm) | 125 | Max. Torque(N.m) | 560 |
| Wheelbase(mm) | 3190+1100 | Displacement(L) | 5.9 |
| Approach Angle (°) | 45 | Departure Angle (°) | 44 |
| Ground Clearance(mm) | 285 | Fording depth (mm) | 1100 |
| Max. Speed(km/h) | 87 | Tank Capacity(L) | 160+60 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
