Photovoltaic panel trailer caravan chassis–Trailer caravan outriggers raised–1.5T trailer caravan export manufacturer

Short Description:


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Product Detail

    Product Tags

    Product Parameter

    Basic Configuration
    Axle 1.5T
    Tyre 185R14C 102H(2)
    Suspension Steel Plate Spring
    Frame 16mn Carbon Manganese Steel Pipe and High Strength Plate Stamping Parts
    Other 1.Reserve electrical connecting wires for tail light and license plate light, etc.
    2.Front tow beam can be upturned 90°, the tractor specification is American Standard 2 inches, with 2 safety chains
    Performance Parameter
    Chassis Dimension(mm) 2920 × 1830 × 740(Length×Width×Height)
    Platform Dimension(mm) 1950 × 1180(Length×Width)
    Total Mass(kg) 1480 Wheelbase(mm) 1970
    Axlebase (mm) 1620 Outrigger Mechanical telescopic manual lift with guard

    This parameter is for reference only. The margin of error is plus or minus three percentage points.
