EQ2082 Long head Six Drive Off Road Truck
Product Description
The engine of this vehicle has improved from EQ6100/6105 gasoline engine for EQ240 to Cummins 6BT5.9 diesel engine.
This classic vehicle has outstanding off-road performance. Six wheel drive can help this vehicle move smoothly in muddy, marsh, forest, gobi and many bad road condition. The lamp protection net, rear window protection net, two fuel tank and 4410N winch can all provide a safety barrier for the wild driving. The convenient detachable tarpaulin pole is included with the truck can effectively reduce the erosion of the goods in the cargo by wind sand and rain.
This vehicle is equipped with off-road tyre that can pass 1100mm wide water area and 285mm obstacle. The vehicle can start smoothly at -41℃. The long head cab can greatly reduce the driver’s injury in the event of an accident.
Product Parameter
| Basic Configuration | |
| Drive Mode | 6×6 |
| Engine | Cummins B170 33 |
| Gearbox | Mechanical Manual five speed |
| Transfer case | Part-time six wheel drive, high-low speed |
| Cab | Dongfeng flat head single row, three seats |
| Axle | Max. Load 2.6Tons/2.6 Tons/2.6Tons (Front/ middle/Rear) |
| Tyre | 11R18 (6+1) |
| Other | The tools, oil bucket, water bucket, fire extinguisher and tarpaulin awning pipe. Optional winch. |
| Performance Parameter | |||
| Overall Dimension(mm) | 6430×2380×2580(Length×Width×Height) | ||
| Cargo Dimension(mm) | 3535×2250×900(Length×Width×Height) | ||
| Total Mass(kg) | 7800(Off-road) | Curb Weight(kg) | 5200 |
| Load Weight(kg) | 2600(Off-road) | Displacement(L) | 5.9 |
| Max. Power(kW/rpm) | 125/2500 | Max. Torque(N.m/rpm) | 560/1300 |
| Frame(mm) | 860×232×75 | Tank Capacity(L) | 160+70 |
| Wheelbase(mm) | 3190+1100 | Wheel Span(mm) | 1774 |
| Approach Angle (°) | 36.8 | Departure Angle (°) | 45.8 |
| Ground Clearance(mm) | ≤285 | Fording depth (mm) | 1100 |
This parameter is for reference only. The margin of error is plus or minus three percentage points.
